Description
Note: This item ships directly from the manufacturer and may arrive separately from other products in your order.
GigBAR Move ILS is a 5-in-1 pack and play system that controls ILS, our patent-pending lighting technology that expanded the possibilities of impressive light show synchronization quickly and easily. GigBAR Move ILS can control any product in the ILS ecosystem, wired or wirelessly. GigBAR Move ILS has moving heads, derbies, washes, a laser, and strobe effect pre-mounted onto a single bar. Easily control the unit via stand-alone, DMX, wireless RF remote or wireless footswitch so you can get to the good times sooner.
Specifications
- DMX Channels: 3, 27 or 46
- DMX Connectors: 3- pin XLR
- Pan and Tilt: 540°/180°
- Colors:(moving head): 7 + white, continuous scroll at variable speeds
- Gobos:(moving head): 7 + open, continuous scroll at variable speeds
-
Light Source:
(pars): 3 LEDs (quad-color RGB+UV) 3.5 W (1 A), 50,000 hours life expectancy
(strobe): 4 LEDs (white & UV) 5 W (1 A), 50,000 hours life expectancy
(derby): 6 LEDs (2 red, 2 green, 2 blue) 1 W (1 A), 50,000 hours life expectancy
(moving head): 1 LED (cool white) 10 W (2.3 A), 50,000 hours life expectancy
(laser): 650nm/100 mW (red) laser diode, 532 nm/30 mW (green) laser diode - Strobe Rate:0 to 20 Hz
-
Beam Angle:(moving head): 11°
(pars): 19°
(strobe): 8° -
Field Angle:(pars): 30°
(strobe): 18° -
Coverage Angle:(derbv): 131°
(laser): 93° - Fits Tripod Size: 1.5 in
-
Illuminance:
(pars): 1,205 lux @ 2 m (per par)
(moving head): 1056 lux @ 2 m (per head)
(strobe): 86 lux @ 2 m (per LED) - Power Linking:7 units @ 120 V; 12 units @ 230 V
- Input Voltage:100 to 240 VAC, 50/60 Hz (auto-ranging)
-
Power and Current:
81 W, 1.1 A @ 120 V, 60 Hz
79 W, 0.6 A @ 230 V, 50 Hz - Weight: 23.4 lb
- Size: 43 x 5.7 x 17.7 in
- Approvals: CE, RoHS, UKCA, FDA, FCC
- Stand Height: 4.8 ft to 8.3 ft
- Tripod leg width: 3.9 ft
- Footswitch Operating Frequency: 433 MHz
- Foot Switch Max Unobstructed Distance: 100 ft
- Footswitch battery: 9 V alkaline
- Included Controllers: RF remote, wireless footswitch
What's Included
- GigBAR Move ILS
- Power cord
- Carrying bag
- Tripod
- Footswitch
- RF Remote
- Quick Reference Guide
